USB2.0 Wireless Lan Card ( BT3 Supporting)

USB2.0 Wireless Lan Card ( BT3 Supporting)

Specifications

• With SMA Adapter (5dBi Antenna)
• Connects at a full 54Mbps via USB 2.0, up to 8 times faster than a USB 1.1 adapter
• High gain upgradeable Compact size for greater flexibility
• Also compatible with USB 1.1 desktop and notebook computers
• Plug-and-Play Compatible with windows 98SE, 2000, Millennium, XP and Linux
• High security 64/128/256bit WEP Encryption, TKIP, WPA, 802.11

Product General

• Standards: Wireless: IEEE 802.11b/g ;  USB 2.0 standard
• Data Rate: 802.11b: UP to 11Mbps ; 802.11g: 54Mbps
• OS Supported: Windows 98SE, Windows ME, Windows 2000, Windows XP, Linux 2.6, Mac 10.4
• Interface: USB 2.0 mini USB
• Antenna Type: 1 x 2.4Ghz SMA connector

Hardware

• Chipset: Realtek 8187L
• One LED: Power/Status, Wireless Act.
• Frequency Range: 2412~2462 MHz (N.A); 2412~2472 MHz (EU); 2412~2484 MHz (Japan)
• Channel: 1~11 channels ( North America ); 1~13 channels ( General Europe); 1~14 channels (Japan)
• Emission Type: DSSS/OFDM
• Output Power: 20 dBm (OFDM),27dBm(CCK)
• Sensitivity for 802.11b: 1, 2 Mbps (BPSK, QPSK): - 96dBm; 11 Mbps (CCK): -91dBm; (Typically @PER < 8% packet size 1024 and @25ºC + 5ºC)
• Sensitivity for 802.11g: 54Mpbs (64QAM): -76dbm, 48Mbps (64QAM): -71dbm; 36Mpbs (16QAM): -78dbm, 24Mbps (16QAM): -80dbm;18Mbps (QPSK): -81dbm, 12Mpbs (QPSK): -82dbm; 9Mbps (BPSK): -85dbm, 6Mbps (BPSK): -91dbm; (typically @PER < 10% packet size 1024 and @25ºC + 5ºC)
• Frequency Stability: within +25 ppm
• Data Modulation Type: BPSK,QPSK, CCK and OFDM
• Power: Voltage 5V+5%
• Security: WEP 64/128, 802.1X support; Wi-Fi Protected Access (WPA); WPA-PSK, WPA II

Environment Spec.

• Operating Temp: 0°C ~ +50°C;
• Storage: -10°C ~ +65°C
• Humidity: 5%~98% non-condensing

Colors Available :

Package Includes :Color Box

Package Includes:Installation CD, USB Cable, User Manual

Packing Information :

• Q'ty/Carton : 30 pcs
• Carton G.W : 13.000 kgs
• Carton Size : 43.000 * 60.000 * 60.000 cm
