VTimage AV VIDEO S-VIDEO TV TO PC Laptop VGA Converter Box
The VT-521 is a Video to VGA converter for High Rosolution (up to 1280*1024) Video Picture sharing. The DEINTERLACE can provide high quality picture and give sharp, stable image output to VGA input device. It is easy to install and operate, instantly switch the source between Video, S-VIDEO and PC with a single button and turn your monitor into a high resolution picture output.
Product Features
- No software drived required
- Resolution: 800*600(60Hz), 1024*768(60Hz) and 1280*1024(60Hz)
- OSD control menu: BRIGHTNESS, CONTRAST, COLOR, HUE
- Compatible for Multi Signal inputs: Video, S-Video, PC(bypass)
- Input Video system 50-to-60HZ frame rate detection (NTSC/PAL)
Connectors of VT-521
- AV In: Connects to Video Out of video source
- SVIDEO In: Connects to S-Video Out of video source
- VGA In: Connects to VGA cable to your PC
- VGA Out: Connects to your VGA monitor
- DC In: Plug with +5.0V power
- Input button: Select the input from VGA in, AV In, Svideo In
- Freeze/+ Button: Press button to freeze image, press button to unfreeze image again
- Reso/- Button: Press button to change RESOLUTION of 800*600(60HZ), 1024*768(60HZ) and 1280*768(60HZ)
- Menu Button: The Menu functions are Brightness, Contrast, Saturation, Hue and Reset.Press Menu button, the VGA monitor OSD can display Brigntess→Contrast→Saturation→Hue→Reset.
>Brightness adjust (for example)
When OSD display Brightness, press "Freeze/+ "button to increment, press" Reso/-" button to reduce
>Reset adjust
when OSD display Reset, press "Freeze/+ "button or " Rose/- button to return default value for brightness, contrast, saturation and Hue
Package Contents
- VT-521 AV to VGA x1
- +5VDC 1000ma Power Adapter x1
- AV Cable x1
- S-VIDEO Cable x1
- VGA Cable x1
- Users Manual x1
