CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL

Rate:
0
(0 reviews)
Item No.: 84001197A Ships in 1 - 3 days MOQ: 1
Email Only Price
Signal System:
Price:
$ 14.85 (0 % OFF)
Qty:
Add to wishlist

Estimated Shipping Cost: loading...

(Ship to loading... via loading... More Shipping Options )

Buy more, save more
Promote Us
+ units
+ units
+ units
+ units
+ units

Specifications

Camera Resolution 1 MP
Camera Shape Outdoor IR Camera
Focus 3.6mm Lens
Home Safety Type Analog Cameras
IP Rating IP66
IR Distance 20m
Sensor Size 1/4"
Sensor Type CMOS
Signal System PAL
With Stand Yes
Gross Weight 0.382kg
Volume Weight 0.418kg
Length 19.100cm
Width 10.500cm
Height 9.300cm
Weight 0.341kg
With Retail Packaging Yes

Product Description

CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL

CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL

  • Progressive 1/4" scan CMOS image sensor

  • 1.0MP 720P high resolution video

  • 3.6mm fixed lens

  • IR-CUT, 24 LEDs, max IR distance 20m

  • IP66 waterproof

  • With retail package

Specifications:

MODELAHD-X5100C
Pickup Device1/4" CMOS(NVP2341H+141)
Horizontal Resolution720P 1.0mp
System of SignalPAL
Lens3.6mm
Backlight CompensationAuto
White BalanceAuto
Shutter Speed1/50(1/60) ~ 1/100,000(sec)
IR LED24pcs LEDS Φ5
Grade of waterproofIP66tgi
S/N RatioMore than 48dB (AGC OFF)
Minimum Illumination0.05lux While IR ON "0" lux
Power ConsumptionWhen the LED turned on, the max electric current is 270mA
Sync SystemInternal Synchronization
Infrared Wavelength850mm
Infrared Lamps Irradiation Distance15m for outdoor, 20m for indoor
Infrared LampsAuto
Video Output1.0VP ~ P,75Ω
BracketGimbal bracket
Dimensions450g (N/W) 675g (G/W)
Power SourceΦ52 L: 160mm

Package included:

  • 1 x CCTV AHD 720P 1.0MP Outdoor IR Camera (AHD-X5100C)
  • 3 x Screws
  • 1 x Installation Instruction
CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL-1 CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL-2 CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL-3 CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL-4 CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL-5 CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL-6 CCTV AHD 720P 1.0MP Outdoor IR Camera 24-LED IR 20m with Bracket IR-CUT (AHD-X5100C) - 3.6mm Lens / PAL-7
